Liquid Packing Machine / PastePacking Machine

Liquid/Paste Packing Machine

The Vertical Form Fill Seal (VFFS) Liquid/Paste Packing Machine with an auger filler is suitable to pack the fillings of sweetened beans paste, filling of lotus meat, fruit jam, tomato sauce, Chinese watermelon jam, lotion, shampoo, detergent and other liquid & semi liquid products. The complete system of this machine includes:

• Screw conveyor feeder
• Auger filler dosing system
• Vertical form fill seal machine (VFFS)
• Finished product conveyor
• Accessory units

Key Advantages

• Simple and Robust Design: Engineered for easy operation and maintenance.
• PLC Controlled Functionality: Ensures precise control over the packaging process.
• Servo-Controlled Mechanisms: Features servo-controlled pulling belts and horizontal sealing for enhanced performance.
• Digital Temperature Control: Provides accurate temperature management for effective sealing.
• Self-Aligning Pulling Belts: Enhance operational efficiency and reduce downtime.
• Photo Sensor Registration: Ensures precise print mark registration.
• Accurate Bag Length Measurement: Utilizes an encoder for exact bag length measurement.
• Tool-less Forming Collar Assembly: Facilitates quick and easy changeovers.
• Convenient Back Seal Alignment: Simplifies the sealing process.

Customization Options

The machine can be customized with various options to enhance its functionality, including:

• Side gusseting assembly
• Block bottom assembly
• Nitrogen gas flushing
• Poly sealing jaws
• Static eliminator
• Forming tube exhaust
• Hole punch/handle punch
• Thermal transfer or laser printer
• Tear notch
• Hopper vibrator
• Indexing conveyor

This Vertical Form Fill Seal Powder Packing Machine provides an efficient and reliable solution for packaging powdered products across multiple industries, ensuring high-quality results with each cycle.

Technical Perameters

• Weight range: 20-5000 ml
• Bag width: 60-390 mm
• Bag length (adjustable): 60-550 mm
• Packing speed: 30-60 bags/min
• Film thickness: 0.04-0.09 mm
• Air consumption: 0.6MPa, 0.4 m³/min
• Power source: 2.2 kW, 220 V, 50 Hz
• Approxiamte machine weight: 600-900 kg

Kind Reminder

Please provide us with the following information when you send your inquiry. Based on your message, we will suggest the optimal solution for your reference. Thank you.

• 1. Bag dimensions
  2. Weight per bag
  3. Your product
  4. Bag shape
  5. Film material
